Product Description
construction type |
textile fire protection curtain |
executable protection target |
EW 90 |
fabric |
Fire & Smoke Fabric E • Stoebich Fire & Smoke Fabric H |
proof |
IBS 08062416 • UL 10D • UL 10 (b) (2009) • UL 10 (c) (2009) • UL 10 (d) (2009) • NFPA 252 (2012) |
closing direction |
from top to bottom |
fire resistant |
2 hours fire rating according to UL 10D, 20 minutes fire rating according to UL 10B, UL 10C, NFPA 252 |
closing cycle |
C1 number of closing cycles 500 |
![Constructive structure - system drawing Constructive structure - system drawing](/typo3temp/assets/_processed_/0/5/csm_stoebich_db_5a8abd52c5bd5_0_dcb3b9b11a.jpg)
1 Smoke detector 2 Casing 3 Side guids 4 Tubular motor 5 Fabric 6 Closing element 7 Coil 8 Control module 9 Control with operating unit 10 Manual release SL System length
Gewebe |
Systemumfang |
Abrolllänge (AL) |
t |
h |
---|---|---|---|---|
Ecotex 1100 A2 |
< 50 m |
< 3 m |
490 mm |
125 mm |
Ecotex 1100 A2 |
< 50 m |
> 3 m - ≤ 6 m |
490 mm |
225 mm |
Heliotex EW 90 |
< 50 m |
< 2,2 m |
490 mm |
125 mm |
Heliotex EW 90 |
< 50 m |
> 2,2 m - ≤ 2,5 m |
490 mm |
225 mm |
Heliotex EW 90 |
< 50 m |
> 4,5 m - ≤ 6 m |
490 mm |
450 mm |
housing
Standard
Special
