SYSTEM: SMOKESHIELD-S | MODEL: SMOKESHIELD-S
Product description
Rectangular or polygonal base area of the smoke curtain. Edge dimensions up to 16 m and roll-out lengths up to 6 m. For high time classes and temperature loads D 120 (600 °C). No residual openings – neither in the upper area nor at the corners. No supports necessary, yet absolutely tight even under high pressure loads. Low installation height of the housing of approx. 125 mm with an AL <3.0 m. Comes standard with the ‘Gravigen’ drive system, i.e. closing without external energy, fire-resistant cables are not necessary. Redundant drive systems as fall protection. Also suitable (approved) as a floor-closing smoke curtain.
| Function | Textile smoke curtain |
| Proof of usability | CE identification pursuant to DIN EN 12101-1:2005+A1:2006 | 0761-CPD-0060 |
| Fabric | Ecotex 1100 A2 |
| Closing direction | From top to bottom |
| Closing cycles | 1000 cycles according to DIN EN 12101-1:2005+A1:2006 |
| Guide type | Guide rails | without guide rails |
| Classification | DH 120 | D 120 | Classification according to DIN EN 12101-1 |
| Release | Approved locking system | On-site |
Legend system components:
1 = Smoke detector
2 = Casing
3 = Side guids
4 = Tubular motor
5 = Fabric
6 = Closing element
7 = Coil
8 = Control module
9 = Control with operating unit
10 = Manual release
SL = System length
AL = Unwinding length
Size dimensions and system structure
The combination of classifications or the ratio of clear system width to clear system height may reduce the stated maximum dimensions and the dimensions of the housing and guide rails may vary. The specifications on the quotation apply.
| Fabric | System scope | Unwinding length (AL) | t (mm) | h (mm) |
| Ecotex 1100 A2 | < 50 m | < 3 m | 490 | 125 |
| Ecotex 1100 A2 | < 50 m | > 3 m - ≤ 6 m | 490 | 225 |
End strip
Standard
Housing
Standard
h = from table
t = 490 mm
d = 290 mm
Specialh = 125 mm
t = 490 mm
d = 290 mm
S = Infrared fuse
